Digilent MCC DT9816-S: Low Cost, Simultaneous USB DAQ Device
DT9816-S from Measurement Computing is a Six channel high-speed, simultaneous sampling USB-based DAQ device
| Ceres::Template.singleItemTechnicalDataAttribute | Ceres::Template.singleItemTechnicalDataValue |
|---|---|
| ID articolo | 103485 |
| Condizione | |
| Modello | 6069-410-137 |
| Produttore | Digilent Inc. |
| Paese di produzione | |
| Numero della tariffa doganale |
Numero di variazione (MEPA): VAR-827003851
Codice produttore: 6069-410-137
Codice doganale:
Il prodotto importato viene spedito da Riedlingen, Germania.
The Measurement Computing DT9816-S is a USB-based DAQ device with six, single-ended, simultaneous analog inputs, 16-bit resolution, 7500 kS/s/ch sample rate, 16 digital I/O, and one counter input. This device is USB powered and requires no external power.
The DT9816-S offers voltage inputs ranges of 10 V and 5 V.
16 digital I/O lines are configurable as eight inputs and eight outputs. The DIO terminals can detect the state of any TTL-level input.
Software support includes QuickDAQ, an out-of-the-box application for data logging, visualization, and signal generation. Data can be viewed in real-time or post-acquisition on user-configurable displays. Drivers are included for the most popular applications and programming languages including Visual C++, Visual C#, Visual Basic.NET, DASYLab, LabVIEW, and MATLAB.
Key Features
- Ultimate flexibility with 6 analog inputs, 8 digital I/O, and one 32-bit counter timer
- 16-bit resolution
- Independent subsystem operation at sample rates up to 750 kS/s per channel
- Simultaneous analog inputs
- Signal range of 10 V on both the analog input and analog output
- Generate sine, rectangle, triangle, or DC waveforms with the analog outputs
- Three versions of digital I/O modules: isolated, nonisolated, and high current drive
- Perform event counting, frequency measurement, edge-to-edge measurement, and rate generation
- Shielded, rugged enclosure for noise immunity, with built-in screw terminals
- Easy signal connections on the DT9812-10V-OEM with two 20-pin connectors for all I/O signals
- All modules run off USB power supply, no external power supply needed
- Includes free QuickDAQ software to get up and running quickly (does not support DIO)
Project Links
Scope of Delivery
- MCC DT9816-S
- USB cable
- Printed insert: QuickDAQ Quick Start
- MCC packaging assembly/foam, etc
References
- Manufacturer: DigilentInc.
- Manufacturer'sarticle name: MCC DT9816-S: Low Cost, Simultaneous USB DAQ Device
- Manufacturer's article number: 6069-410-137
