Digilent MCC USB-DIO24H/37: Digital I/O USB device with 24 high-current channels
USB-DIO24H/37 from Measurement Computing provides 24 high-current logic level digital I/O lines for each USB port.
Código de artículo VAR-827003891
Número de pieza del fabricante: 6069-410-055
Código aduanero:
El producto importado se envía desde Riedlingen, Alemania.
The Measurement Computing USB-DIO24 Series offer 24 lines of logic-level digital I/O to any USB port. Each device is USB-powered and requires no external power.
Each USB-DIO24 Series device has 24 digital I/O lines configured as three 8-bit ports. Each bit is individually configurable for input or output.
The USB-DIO24H/37 is designed to emulate 82C55 mode 0. Outputs are high-drive TTL that can source 15 mA and sink 64 mA.
The 32-bit event counter pin counts TTL pulses and accepts frequency inputs up to 1 MHz.
Software support includes DAQami, an out-of-the-box application for data logging, visualization, and signal generation. Data can be viewed in real-time or post-acquisition on user-configurable displays. Drivers are included for the most popular applications and programming languages including Visual C++, Visual C#, Visual Basic.NET, DASYLab, LabVIEW, MATLAB, Linux, and Python.
Key Features
- 24 digital I/O lines
- 24 mA drive capability
- Digital output alarm
- One 32-bit event counter (shared with a DIO pin)
- Remote network configuration
- The 37-pin connector provides 24 digital I/O, one counter, six ground, and two power connections.
- The digital I/O port is configured as two 8-bit and two 4-bit ports based on an 82C55 mode 0 emulation.
- You can configure each port independently for input (default) or output.
- The CTR signal is the input to the 32-bit external event counter.
- USB-DIO24/37 digital type: 82C55
- USB-DIO24H/37 digital type: 74FCT244 (output), 74ACT373 (input)
- USB-DIO24/37 sink / source: 2.5mA
- USB-DIO24/37 sink / source: 64 mA / 15 mA
- 5.5 V max inout voltage
Project Links
Target Applications
- Digital I/O and Control
- Remote Digital I/O
Scope of Delivery
- MCC USB-DIO24H/37
- USB cable
- Printed insert: DAQami Quick Start
- MCC packaging assembly/foam, etc.
References
- Manufacturer: DigilentInc.
- Manufacturer'sarticle name: MCC USB-DIO24H/37: Digital I/O device with 24 high-current channels, 37-pin connector
- Manufacturer's article number: 6069-410-055
